Description
- Rated Line Pull: 4500 lbs.
- Motor: 12V DC, 1.7 hp Permanent Magnet
- Gear Ratio: 166:1
- Gear/Transmission: All-metal Planetary Gear Drive
- Brake: Dynamic and Mechanical
- Clutch (free spooling): All Metal Cam Activated Freespool
- Drum Size: 2" (D) x 3.19" (L)
- Cable: 15/64" (D) x 38' (L)
- Fairlead: Multi-directional Roller
- Control: Deluxe Handlebar Mounted Mini-Rocker Control Switch with
- optional dash mount bracket and a Heavy Duty Corded Remote Switch
- Winch Dimensions: 14.6" L x 4.55" D x 5" H
- Mount Plate: Fairlead Mount Only (A Model Specific Mount is necessary for your make and model UTV)
- Mounting Bolt Pattern: 3.00" x 4.875" (4-Hole)
- Recommended Battery : 12 Amp/hour minimum
- Warranty: Limited 1 Year
- Winch Weight: 36.6 lbs. (complete kit)
