Description
Features
- Comes with #0521-2109 Modular Grill and #4505-1118 Modular Winch Mount
- Able to be mount to the front face and also the Top Surface as an option
- Replaces stock plastic grill
- Constructed of 3/16" steel
- Metal bead blasted before they are powder coated for the best possible finish prep and durability
- Easy to install
- Complete installation instructions included
- Roller fairlead and winch not included
- Made in the USA
- KFI: ST17 / S2000 / A2500 / A3000 / U4500 / U4500w / SE25 / SE35 / SE45 / SE45w
- KFI: AS-25 / AS-35 / AM-25 / AM-35 / AS-50 / AS-50w
- WARN: A2000 / A2500 / U2500 / 1.5ci / 2.5ci / 2.5ce / 3.0ci / 3.0ce / 3.0s
- WARN: RT15 / RT25 / RT30 / XT15 / XT25 / XT30
- WARN: RT40 / XT40
- WARN: Vantage 2000-3000lbs / Provantage 2500-3500lbs
- WARN: Vantage 4000lbs / Provantage 4500lbs
- RAMSEY: ATV2500 / ATV3000
- SUPERWINCH: Terra25 / Terra35 / Terra 45 / A3500 / LT2000 / LT2500 / LT3000 / LT4000ATV / LT4000UTV
- MILE MARKER: PE2.5 / PE 3.5 / VMX2.5 / PE2000 / PE3000 / PE2500 / PE3500
- CYCLE COUNTRY: Work Power 1500 and 2500 / Powermax 2500 and 3500
- BADLAND: 2-Hole Winches, Standard Winches, WIDE Winches
- CHAMPION: 2-Hole Winches, Standard Winches, WIDE Winches
- KEEPER CORP. TRAKKER: KT2500 / KT3000 / KT2500C / KT3000C / KT4000 / KT4000C
- KEEPER CORP. TRAKKER: KT2000 requires roller fairlead with a 4.875" bolt pattern
- SMITTYBILT: XRC 2.0 requires roller fairlead with a 4.875" bolt pattern
- SMITTYBILT: XRC 3.0 / XRC 4.0
- XGEAR: X3000 / X4000 4-Hole Standard (3.00" x 4.875" bolt pattern)
- VENOM: 2000 / 2500 / 3000 / 3500 / 4000 / 4500 / 5000 (Hardcore Series 3.00" x 4.875" and 3.00" 6.600" bolt pattern mount-up)
- Traveller: 1078311
- Traveller: 1078088 / 1078302 requires roller fairlead with a 4.875" bolt pattern
- QUADBOSS: RP25 / RP35
- Possibly many others with these standard mounting patterns: 4-Hole 3.00" x 4.875" bolt pattern with rollers that are 4.875" bolt pattern, 4-Hole WIDE 3.00" x 6.60" bolt pattern with rollers that are 6.600" or 6.000" bolt pattern, or 2-Hole 3.10" with rollers that are 4.875" bolt pattern
| Position | Notes | |||
|---|---|---|---|---|
| 2013-2015 | Arctic Cat | Wildcat 1000 | - | - |
| 2013-2014 | Arctic Cat | Wildcat 4 1000 | - | - |
